AMS Neve 1073 SPX-D
- Legendary 1073® preamp with discrete class-A circuitry and Marinair transformers
- High-performance USB and ADAT digital audio interface
- 9 inputs (1× analog / 8× ADAT) and 12 outputs (4× analog / 8× ADAT) with expandable I/O
- Class-compliant USB for plug-and-play DAW integration
- ADAT ports function as USB/ADAT hub or ADAT Audio Expander
- Route any DAW track through 1073SPX-D analog circuitry including transformers and inductor EQ
- Comprehensive monitoring controls for speakers and headphones with attenuation and blend
- 5dB stepped gain control with three independent gain stages
- Musical three-band inductor EQ with hand-wound inductors
- Extensive analog I/O with front/rear connections, insert loops, and rotary output fader (-inf to +5 dB)
- Seamless integration with additional hardware units and flexible studio workflows
Product information "AMS Neve 1073 SPX-D"
The 1073SPX-D merges the legendary 1073® preamplifier with a high-performance digital audio interface, providing USB and ADAT connectivity for seamless integration into any studio, live sound, or mobile recording setup. Combining a complete 1073 channel strip with versatile I/O capabilities, the 1073SPX-D serves as a central hub for recording, mixing, and monitoring. With nine inputs (1× analog / 8× ADAT) and 12 outputs (4× analog / 8× ADAT), this unit can manage multiple audio sources and expand easily with additional hardware.
Featuring a class-compliant USB interface, the 1073SPX-D offers plug-and-play simplicity for direct DAW integration on PC or Mac, while its ADAT ports operate in dual modes: as a USB/ADAT hub for expanding recording and monitoring capacity or as an ADAT Audio Expander to integrate the 1073 channel strip into existing systems. This digital option allows tracks in your DAW to be routed through the 1073SPX-D’s discrete class-A circuitry, including Marinair transformers and inductor-based EQ, before returning via USB or ADAT.
The 1073SPX-D includes comprehensive monitoring controls, enabling direct connection of studio monitors and headphones with attenuation, speaker cut, and blend control for latency-free monitoring of both DAW tracks and the 1073SPX-D signal. Retaining the classic 1073 discrete class-A topology and Marinair transformers, the 1073SPX-D delivers the authentic 1073 sound while combining modern production techniques, including SMT assembly and hand-mounting of critical components.
Accurate 5dB stepped gain control, three independent gain stages, and a musical three-band inductor EQ ensure professional-level sound shaping, while extensive analog I/O, switchable front/rear connections, balanced insert loops, and a rotary output fader provide full control over signal flow and studio integration.
AMS Neve
AMS Neve Ltd,
AMS Technology Park, Billington Road, Burnley, Lancashire, BB11 5UB
info@ams-neve.com
https://www.ams-neve.com/
Genuine 1073 transformer-coupled microphone preamplifier / EQ circuit in a single 1U 19″ rack-mount enclosure
2× Balanced Analogue Monitor XLR Line Outputs
1× Balanced TRS Headphone Output
8× ADAT Digital Inputs & 8× ADAT Digital Outputs via TOSLINK Connection
Exclusive Neve Marinair transformers on input and output stages
USB 2.0 B-Type port for direct connection to Mac or PC, Class Compliant – Core Audio/ASIO
Front & rear Mic & Line inputs, front DI input
Switchable +48V Phantom Power, Hi/Lo impedance, -20dB pad and DI ground lift
Switchable Phase and EQ in/out
Pre/Post-EQ insert send/return loop
7-stage LED signal level meter – mic/line/DI input-stage, EQ-stage, or output-stage level up to +24dB
Output level control: -inf → +5dB
External multi-voltage PSU with locking 5-pin XLR Connection
Preamp Specification
Microphone Input: Gain +80dB to +20dB in 5dB steps
Line Input: Input impedance 10kΩ, gain +20dB to -10dB in 5dB steps
DI Input: Input impedance 2MΩ (PAD off) / 200kΩ (PAD on), Gain +80dB to +20dB in 5dB steps
EQ Specification
High Frequency: Smooth ±16dB shelving at 12kHz
Low Frequency: Smooth ±16dB shelving, selectable 35Hz, 60Hz, 110Hz, 220Hz
Mid Frequency: Smooth ±18dB peaking, fixed Q, selectable centre frequencies 0.36kHz, 0.7kHz, 1.6kHz, 3.2kHz, 4.8kHz, 7.2kHz
High Pass Filter: 18dB/oct slope, switchable 50Hz, 80Hz, 160Hz, 300Hz
Audio Performance
Output: Maximum >+26dBu into 600Ω, transformer balanced, earth-free, Output Impedance 75Ω @1kHz
Distortion: ≤0.07% from 50Hz to 10kHz at +20dBu output (80kHz bandwidth) into 600Ω
Frequency Response: ±0.5dB 20Hz–20kHz, -3dB at 40kHz (EQ Out)
Noise: -82dBu at all line gain settings (22Hz–22kHz)
EIN: Better than -125dBu @ 60dB gain
Monitor Output Specification
Maximum output level: +20dBu
Headphone Output Specification (600Ω load)
Maximum output level: +20dBu
Frequency Response: 20–20kHz ±0.5dB
Distortion (THD+N): <0.005%
Noise floor: -90dBu
A/D Specification
Maximum input level: >+26dBu
Dynamic Range: 119dB
Noise (THD+N): <100dBFS
Distortion: <0.002%
D/A Specification
Maximum output level: +26dBu
Dynamic Range: 117dB
Noise (THD+N): <91.5dBu
Distortion: <0.001%
Dimensions
Width: 480mm (19 inches)
Height: 44mm (1.75 inches)
Depth: 360mm (14.7 inches)
Approx. Weight: 5.475kg (12.07 pounds)
