Austrian Audio CC8 Microphone
Entdecken Sie das Austrian Audio CC8 Mikrofon mit präzisem Cardioid-Muster, robustem Design, schaltbarem Hochpassfilter und analogem Pad für top Soundqualität.
Product information "Austrian Audio CC8 Microphone"
- Handmade OCC7 condenser capsule
- Inspired by a legend, this newly developed capsule takes on the heritage with the benefits of the classic and the demands of today.
- High precision cardioid pattern
- directional characteristic
- Rugged Design
- Metal housing, cap, and grille
- Switchable high pass filter
- 60 Hz (2nd order), 120 Hz (2nd order)
- Two different types of analogue pads
- Pads (0, -10 dB, -20 dB) to enable to pick up sound up to 156dB
- Match-paired out of the box
- Each microphone is measured and tuned to a tolerance of max. +/-0.5 dB sensitivity at 1 kHz.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Austrian Audio
Austrian Audio GmbH
Eitnergasse 15 1230 Wien AUSTRIA
office@austrianaudio.com
https://austrian.audio/
Directional characteristic:
Cardioid
Frequency range:
20Hz - 20kHz
Sensitivity:
15 mV/Pa
Equivalent noise level:
16 dB SPL (A)
Max. SPL:
156 dB SPL
HP filter:
60 Hz (2nd order), 120 Hz (2nd order)
Switchable pad:
-10 dB, -20 dB
Impedance:
275 Ω (symmetrical)
Load impedance:
> 1 kΩ
Supply voltage:
48 V (< 3 mA)
Main Connector:
XLR 3 pin
Dimensions:
140 x 23 x 23 mm
Weight:
160g
