Barefoot Sound Master Stack 12 no handles

€59,990.00*

Prices incl. VAT plus shipping costs

Availability: Please contact us in urgent cases.

Features

3,500 Total Watts of Power
Eight 12” aluminum cone Dual-Force™ Subwoofers
Bass Response Down to 18 Hz
MEME™ Technology

Product information "Barefoot Sound Master Stack 12 no handles"

The MasterStack12 represents the pinnacle of Barefoot’s achievements in monitor speaker design to-date. Barefoot’s flagship reference monitor system is a 4.5-way active modular tower with 10 drive units — a 1-in. ring radiator tweeter, two 2.5-in. mid-range, three 7-in. woofers and four 12-in. subwoofers — housed in two cabinets. A third enclosure houses signal and power distribution and may be optionally used as a decoupling base unit for each tower.

Safety Warnings:	Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt.

Barefoot Sound

1710 NW Upshur St, Portland, OR 97209, United States

questions@barefootsound.com

https://barefootsound.com/

ES-ProAudio

Narzissenstr.9, 85055 Ingolstadt

contact@es-proaudio.de

All products

Description:	4.5-way active modular tower monitor with MEME™ Technology
Controls:	Analog/AES3 input select, AES3 L/R channels select, Input level stepped attenuator, Subwoofer level, Emulation voice select
Input Impedance:	25k Ohm
Frequency Response:	18Hz – 50kHz (±3dB) 26Hz – 40kHz (±1dB)
Bass Response:	-3 dB @ 18Hz, Q = 0.707 Slope = 12 dB/octave
Cabinet:	180 liters total internal volume, Sealed sub enclosures, Sealed woofer enclosures, Sealed woofer enclosure, Machined aluminum baffle plate, Aluminum subwoofer frames function as lateral cabinet bracing, Long fiber wool acoustic damping throughout.
Crossover Frequencies:	80 / 200 / 800 / 4000 Hz
Tweeter:	1″ ring radiator, Advanced geometry motor, Rear waveguide chamber Amplifier: 250W Hypex
Midranges:	2 x 2.5″ aluminum cones, Advanced geometry motor, +/- 2 mm linear excursion Amplifier: 250W Hypex
Woofers:	3 x 6.5″ aluminum cones, Advanced geometry motor, +/- 13 mm linear excursion Amplifier: 500W Hypex
Subwoofers:	4 x 12″ aluminum cones, Advanced geometry motor, +/- 25 mm linear excursion Amplifier: 2400W Hypex
AC Power Input:	Nominal 115 VAC or 230 VAC selectable
Power Consumption:	Idle: 100W, Maximum: 1800W
Weight:	Weight: 280 lbs per tower (127 kg) – no handles Shipping: 325 lbs per tower (147 kg) – no handles
Dimensions HxWxD:	Cabinet: 63.0 x 14.4 x 21.9 inches (1600 x 366 x 556 mm) Footprint WxD: 23.0 x 21.5 (584 x 546 mm)
