Digigram ALP222e
Discover the Digigram ALP222e PCIe stereo sound card with 24/7/365 usage, analog/digital connections, low-latency drivers, and advanced 8×8 mixer.
Features
- Outstanding Audio Quality and Performance: Rock-solid reliability for 24/7/365 use.
- Zero Latency Mixer: FPGA-based for seamless audio processing.
- Versatile Connectivity: Supports analog and digital I/O, including AES3 and Word Clock.
- Expandable and Scalable: Supports up to 8 ALP-X cards in a single system.
- Multi-OS Support: Compatible with Windows 10/Server 2016 and various Linux distributions (Ubuntu, Debian, RHEL).
Product information "Digigram ALP222e"
ALP222e is a low profile PCIe stereo sound card designed for operating in continuous 24/7/365 use-environments, as part of professional audio applications based on Windows or Linux operating systems. The card offers analog and digital audio connectivity, and features an on-board 8×8-channel mixer that allows for the routing and mixing inputs to the outputs.
The low latency drivers are multicard (up to 8 ALP cards) and multi-client.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Digigram
Digigram Digital SAS
82-84 allée Galilée, 38330 Montbonnot-Saint-Martin
marcom@digigram.com
https://www.digigram.com/
Technical Specifications:
- Dimensions: 168 mm x 69 mm x 20 mm (6.6 inch x 2.7 inch x 0.8 inch)
- Form Factor: Low profile (includes standard and low profile brackets)
- Expansion Bus: PCIe x1 (compatible with x2, x4, x8, x16 slots)
Inputs:
- Analog: 2 balanced line level, A/D converter 24-bit/192 kHz, adjustable gain (analog: -88 dB to +39 dB, digital: -90 dB to +12 dB)
- Digital: 1 stereo AES3 input, adjustable gain (-90 dB to +12 dB), multiple sample rates (32 to 192 kHz)
- Other: 1 AES11 sync input, 1 Word Clock sync input, 2 dry contact GPIs
Outputs:
- Analog: 2 servo-balanced line outputs, D/A converter 24-bit/192 kHz, adjustable gain (-90 dB to +12 dB), 1 stereo headphone output
- Digital: 1 stereo AES3 output, adjustable gain (-90 dB to +12 dB), multiple sample rates (32 to 192 kHz)
- Other: 2 relay GPOs, 1 Word Clock output
Audio Performance:
- Frequency Response: 20 Hz – 20 kHz
- SNR: Inputs >110 dBA (A-Weighted), Outputs >115 dBA (A-Weighted)
- THD + Noise: Inputs <-96 dB @18 dBu, Outputs <-101 dB @18 dBu
- Crosstalk: Inputs -111 dB @1 kHz, Outputs -130 dB @1 kHz
Synchronization Sources:
- Internal Clock: Multiple frequencies from 11.025 kHz to 192 kHz
- AES11 and Word Clock Input: 32 kHz to 192 kHz
- Intercard Clock: Synchronize up to 8 ALP-X cards
Drivers and Software:
- Drivers: ASIO, WASAPI/DirectSound for Windows; ALSA for Linux
- Control Panel: Digigram ALP-X ASIO Settings and ALP-X Manager for Windows, supporting multi-card configurations and different working modes (light and full).
Included Accessories:
- Breakout cable (1 m) with XLRs for audio I/Os and AES11 input, BNC for Word Clock I/O, DB9 for GPIO, and 3.5 mm TRS jack for headphones.
