Grace Design m303s
Features
- Transparent, musical audio performance like all Grace Design products
- Active design with true galvanic isolation
- Two world-class transformers from Lundahl
- Incredibly low distortion and noise with wide dynamic range
- Deep, rock-solid bass reproduction
- 1 M Ohm input impedance
- Durable, designed for years of reliability
- With a 5-year warranty
- Made in the USA
Product information "Grace Design m303s"
The brand-new Grace Design m303S is an active, isolated DI box engineered for the next generation of live and studio applications. The advanced power supply design provides incredible headroom and extended dynamic range.
Two custom-wound Lundahl transformers deliver astonishing low-frequency clarity and high-frequency detail. All this
power is packaged in a beautiful and robust ¼-inch extruded aluminum enclosure. Don't let the sleek exterior fool you; this DI box is rock-solid.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Grace Design
Grace Design
4689 Ute Highway, Longmont, CO 80503
dwood@gracedesign.com
https://gracedesign.com/
For-Tune Vertrieb
Brinzingerweg 13
D-73732 Esslingen am Neckar
0711-46915185
service1@for-tune.de
https://for-tune.de/
- Phantom powered active DI with full galvanic isolation.
- Specially wound Lundahl transformer, magnetically shielded with a highly nickel-plated core
- Extremely low distortion (less than -100 dB at 1 kHz, less than -80 dB at 50 Hz)
- Extremely low noise (-118 dBu, A-weighting)
- Ultra-wide bandwidth 20–80 kHz
- Wide dynamic range (124 dB)
- Excellent low frequency headroom THD+N at 50 Hz <-80 dB (0.007%)
- 1 M Ohm input impedance works with any line or pickup signal source
- Peak indicator LED – 3 dB before clipping
- Power indicator LED
- Efficient design draws only 4 mA phantom power
- Continuous signal connection
- Fully ESD and RFI protected
- Input pad (13 dB) for high-level signals
- High-quality toggle switches with gold contacts
- Very robust 1/4″ wall housing made of extruded aluminum, recessed connections
