Mesanovic CDM65 single
Discover the Mesanovic CDM65 single 3-way active DSP speaker for superior HiFi and studio monitoring with wireless audio transmission.
Product information "Mesanovic CDM65 single"
The CDM65 is a 3-way active DSP speaker designed for uncompromised performance and connectivity. It has the unique ability to upload various predefined tunings to the speaker such as the cardioid mode, which controls the directivity of the speaker down to 150Hz. The CDM65 can also receive wireless audio from any WiSA transmitter or from the Platin Stereo Hub. These features make the CDM65 a perfect fit for studio monitoring as well as home HiFi listening.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Mesanovic Microphones
Den für das Produkt verantwortlichen Wirtschaftsakteur finden Sie
auf dem Produkt, der Verpackung oder in einer dem Produkt beiliegenden
Unterlage.
All products
Drivers
High: 1” aluminum dome waveguide tweeter
Mid: 5” aluminum cone woofer
Low: 2 x 6.5” paper kevlar subwoofer
Amplification
Class D
High: 150W
Mid: 150W
Low: 300W
Cabinet
Height: 15”
Width: 8”
Length: 14”
Weight: 32 lbs
Frequency Response
40Hz-20kHz ±1.0dB
-3dB @ 36Hz
Harmonic Distortion
Measured at 96dB SPL @ 1m
> 85Hz ≤ 1.0 %
Max SPL
103dB from 40Hz per speaker before limiting
(Tested at 1m with continuous full bandwidth
20Hz-20kHz pink noise)
Crossover Frequencies
150Hz & 2300Hz
Connections
Balanced XLR Input, WiSA Wireless,
Auto switching 115/230V
Standby Mode
The speaker will enter a standby mode if no audio signal is detected for 20 minutes.
