Peluso P24
- Heavy-duty medical grade 12-pin screw-on connector and cable system
- Single 6072AM glass twin triode vacuum tube powering both circuits
- Two independent hand-soldered through-hole component circuit boards
- Historically accurate P-CK-12 capsule design matching vintage CK 12 capsules
- Capsules manufactured with exacting tolerances for perfect stereo matching
- Upper capsule assembly with 180° rotation and custom swivel design
- Dual isolated 14/1 custom-wound output transformers for clean balanced signals
- Stereo power supply unit with rugged 12-pin connector, dual XLR outputs, and 9-pattern controls
- Switchable power settings for 115v or 230v regions
Product information "Peluso P24"
The Peluso P-24 is a modern tribute to the legendary AKG C 24 stereo tube condenser microphone. It houses two complete large diaphragm tube condenser systems in one body, with the upper capsule capable of 180° rotation for coincident stereo techniques like X-Y, Mid-Side, and Blumlein. Each capsule offers 9 selectable polar patterns, controlled remotely via the power supply. Both circuits run independently with isolated custom transformers and through-hole component boards, powered by a single vintage 6072AM glass triode tube. The unique dual-circuit design enhances low-end response and delivers a smoother, fuller top end, while the redesigned P-CK-12 capsule ensures historical accuracy and outstanding stereo imaging.
Peluso Microphone Lab
Peluso Microphone Lab
1778 Horse Ridge Rd NW Willis, VA 24380
https://pelusomicrophonelab.com
Capsule Type: Dual historically accurate P-CK12 32mm condenser pressure gradient, edge terminated
Frequency Range: 20 Hz – 24 kHz
Polar Pattern: 9 – Switchable from omni- to bi-directional
Sensitivity: 11 mV/Pa
Impedance: 200 ohms
Maximum SPL: 138 dB
Equivalent Noise: 15 dB(A)
Tube Type: Single 6072A-M
Transformer: Dual T-14/1
Power Requirements: Dedicated power supply, 115V or 230V AC
Size: 50 mm x 269 mm
Weight: 1058 g
