Product information "RTW TouchControl 5 Ravenna"
Meet TouchControl 5, our Dante®- or RAVENNA®-based (now available) immersive monitor controller with metering.
Continuing our legacy of excellence in broadcast-grade monitor controllers, the TouchControl 5 redefines what’s possible by seamlessly uniting advanced metering with powerful monitor control - giving you the best of both worlds in a compact format with a small footprint.
It comes fully loaded with RTW’s trusted, loudness-compliant metering tools and an industry-leading monitor control engine that supports a wide range of speaker formats, speaker calibration, bass management, downmixing, and multiple input configurations.
Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
---|

- Immersive table-top monitor controller and meter with 5” touch display and 32 Dante® or RAVENNA® channels
- Support for stereo- surround and -immersive speaker formats including 5.1 and 7.1.4
- Support of array speaker layouts according to Dolby® guidelines
- Comprehensive monitor control feature set with speaker calibration, SPL measurement, bass management and up to 4 sources/destinations
- RTW precision metering with customizable bargraphs and support for international loudness standards
- Audio Vectorscope, Real Time Analyzer, Loudness Chart
- Toolbox with independently routable leveling and talkback
- Customizable view pages
- Built-in microphone preamp with +48 V phantom power
- Built-in calibrated microphone for talkback and SPL measurement
- Powerful Headphone Output: 1/4 inch Headphone output with the option of monitoring a user-defined downmix
- Analog Speaker Output: 3.5mm speaker output with the option of monitoring a user defined downmix
- Easy Setup with Web-based Interface
- Power over Ethernet (PoE – IEEE 802.3af compliant)
- Sample rate up to 96 kHz
- Assignable knob press action: DIM, Mute, Recall of Calibrated Level
- Lockable Operation Mode: Fool-proof setup with access only to relevant controls. Prevents unintentional operation during showtime
