Solid State Logic SSL UMD192

€2,999.00*

Availability: Please contact us in urgent cases.

Manufacturer: Solid State Logic

Features

192 Channel USB 3.0 Computer Interface
192 Channel MADI 6x BNC
192 Channels at 96/48kHz or 128 Channels at 192kHz
192 Channel Dante
Power Over Ethernet
Compatible with Mac and Windows

Product information "Solid State Logic SSL UMD192"

Built for versatility, the UMD192 supports bidirectional audio between any two formats – MADI, Dante or USB – with the third format able to receive a split feed. This makes it ideal for bridging multiple MADI-connected devices into a Dante network, or for high-channel-count recording and playback via USB 3.0.

Safety Warnings:	Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt.

Solid State Logic

Solid State Logic UK Limited

Spring Hill Road Begbroke Oxford OX15 6DS

marketing@solidstatelogic.com

KLANG:TECHNOLOGIES GMBH

Wespienstraße 8-10 52062 Aachen Germany

contact@KLANG.com

All products

192 channels at 48/44.1 kHz, 192 channels at 96/88.2 kHz, and 128 channels at 192/176.4 kHz
USB 3.0 class-compliant interface
Mac OS compatible; Windows support via SSL driver
6x MADI BNC pairs with redundant mode for 3x dual-redundant MADI connections
Fully interoperable Dante AoIP with AES67 and ST 2110 (with DDM) support
Ultra-low Dante latency—as low as 0.25ms
Flexible clocking from MADI or Dante
Ruggedised Ethernet ports (2x Primary, 2x Secondary) with Link & Activity LEDs
Clear front-panel indicators for signal flow, sample rate matching, power status, and connectivity
Intuitive front-panel controls, with a lockout feature to prevent accidental changes during operation.
Multiple power options: AC, PoE, or USB—with redundancy support
Lightweight and portable design for desktop, console-side, or rack-mounted use
Included cables: USB-C to C, USB-A to C adapter, IEC power cable
