Soyuz Lakeside Preamp
Product information "Soyuz Lakeside Preamp"
The Soyuz "Lakeside" preamp is a fully discrete, single-channel Class-A preamplifier with a distinctive sound that stands out in the signal chain and enhances recordings.
By using custom transformers on both the input and output and through meticulous craftsmanship, the Lakeside adds rich character and dimension to any microphone, instrument, or source.
The Lakeside is the perfect choice for recording vocals, bringing them to life, for guitars, adding emotional depth, for drums, providing full and voluminous texture, and for any other source that requires a colored and characteristic finishing touch.
This easy-to-use and remarkably versatile preamp provides an effortlessly "finished" sound for any recording, making it an essential component of any studio or setup.
| Safety Warnings: | Die spezifischen Sicherheitshinweise für das Produkt sind in dessen Bedienungsanleitung aufgeführt. |
|---|
Soyuz
Soyuz
3355, Wilshire Blvd. suite 616,
Los Angeles, CA, 90010, USA
https://soyuzmicrophones.com/
Single-channel Class-A preamp for rackmount (1U)Fully discrete through-hole circuitCustom-wound input and output transformersStepped input gain switch in 5 dB incrementsSmooth output trim controlUnique inductor-based high-pass filter (40 Hz to 330 Hz)Built-in 1/4" DI on the front panelMicrophone input impedance: 1.2kDI input impedance: > 1MOutput impedance: < 80 ohmsGain boost: 10-60dB in 5dB stepsFrequency response: 20Hz-20kHz (±0.5dB) with 40dB gain at 600 ohm load8Hz-40kHz (±5dB) with 40dB gain at 600 ohm loadEquivalent input noise: 120dB with 40dB gain at 600 ohmsTHD+N: <0.02% at 40dB gain, loaded at 600 ohms with an output level of +18dBuCutoff filter 18dB/oct (-3dB) = 40, 55, 70, 90, 120, 150, 180, 220, 270, 330HzMax output: +27dBu (0.2% THD), +31dBu (1.5% THD)Versatile: offers both clean headroom with characteristic coloration and harmonic distortionSuitable for re-amping stems, recordings, and entire mixesDimensions: 48.3 cm (19") x 21.6 cm (8.5") x 4.4 cm (1.75")Weight: 5.9 kg
