WesAudio Dione
€1,079.00*
% €1,199.00* (10.01% saved)Availability: Please contact us in urgent cases.
- 100% analog design – pure signal path with +24 dBu headroom, powered by THAT 2181 VCA
- Parallel compression control – dedicated MIX knob for easy blending
- THD control – selectable Medium and High modes for harmonic saturation
- Advanced sidechain filtering – 3 high-pass filters (60 Hz, 90 Hz, 150 Hz) and 2 tilt filters with custom curves
- Flexible ratio settings – 1.5:1, 2:1, 4:1 and 10:1 for various compression tasks
- Series compatibility – supports 500 Series and ng500 Series systems (e.g., _TITAN)
Product information "WesAudio Dione"
The legendary sound of the stereo bus compressor has been a cornerstone of countless recordings for over 40 years, often referred to as “mixbus glue.”
This compression style has defined the industry standard, delivering cohesion, punch, and musical balance to mixes.
Introducing _DIONE — a fully analog, iconic VCA compressor that builds on this classic sound.
Enhanced with digital recall, it integrates seamlessly into modern studio workflows.
_DIONE combines timeless sonic character with modern control, making it an ideal tool for professional mixing and mastering applications.
| Safety Warnings: | The specific safety instructions for the product are provided in its user manual. |
|---|
WesAudio
Wes Audio Sp. z o.o.
Zegadlowicza 54 PL-71-370 Szczecin Poland
info@wesaudio.com
- Technical Data:
- Frequency response: 20 Hz – 20 kHz (0.1 dB)
- THD+N (WET): 0.008% (1 kHz, 0 dBu)
- THD+N (DRY): 0.004% (1 kHz, 0 dBu)
- Input impedance: 10 kOhm
- Output impedance: <100 Ohm
- Maximum gain: 21 dB
- Crosstalk: <-90 dB
- Attack: 0.1 / 0.3 / 1 / 3 / 10 / 30 ms
- Release: 0.1 / 0.3 / 0.6 / 0.9 / 1.2 / Auto ms
- Ratio: 1.5 / 2.4 / 10
- Sidechain filter: 60 / 90 / 150 / T1 / T2
- THD (MID switch): 1%
- THD (HIGH switch): 4%
- Power consumption: 70 mA/+16V and 50 mA/-16V (per slot)
- Dimensions: 76 × 133 × 158 mm
- Box dimensions: 105 × 162 × 234 mm
- Unit weight: 0.6 kg
- Box weight: 0.8 kg
- Warranty: 2 years
